  • Model Number: MU-14006
  • Brand Name: ADG
  • Application: For Commercial & Home Use
  • Product name: body composition analyzer
  • Product description: Type:Other Place of Origin:Guangdong Function:Body health analyzer Warranty:3 Years Service:OEM/ODM 24 hours service Voltage:110/220v Color:white Certification:CE ISO CFDA Style:Staionary Tes
  • INQUIRY

High accuracy body composition analyzer bodyfat scale for clinics/home/salon

Multi function body fat analyzer composite health analyser weight measurement

Technical Parameters

Test Method

Multi-frequency bioelectrical impedance analysis (MFBIA)

Test Part

bioelectrical impedance analysis on the part of left upper limb, right upper limb, trunk, left lower extremity, right lower extremity

Test Frequency

Three differenct frequency(20KHZ, 50KHZ, 100KHZ)

Electrode Method

8 point contact eletrode

Computing method of body components

Do not estimate through empirical value

Output Value(25)

TBW, protein, mineral salt, Body fat, bone weight, Weight,IBW, fat-free weight, SMM(Skeletal muscle), BMI(Body mass index), PDF(percentage of body fat), WHP(waist-hip ratio),moisture ratio, Obesity diagnosis, nutritional assessment, Weight assessment, obesity assessment, Goal weight,Weight control,Fat control, Muscle control, Health assessment, basic metabolism, bioelectrical impedance.

Rated current

less than 180μA

Power

Input power: AC100~240V, 50/60HZ

Screen

320*240 STN LCD Touching Screen

Operation Language

English and Multiple Language Option

Values Storage

50000×10 and SD Card unlimited expansion is available

External Storage

SD Card tranfer to computer for large storage

External Interfaces

RJ-45, USB2

Printer Interfaces

USB

IC Card System

standard IC card control

Printer

A4 color paper ink-jet printer(manufacturers appoint the model), internally installed thermal printer

MEAS. Of Package

49CM*50CM*118CM (woodern case), GW: 40KG; NW:32KG.

Test time

No more than 2 minutes

Operation Environment

Temperature: 10~400°C(50~1040°F),humidity: 30~80%RH, 500~600hPa

Conservation Environment

Temperature: 0~400°C(32~1040°F),humidity: 30~80%RH, 500~600hPa

Test scope of weight

10~200Kg; Test scope of age: 10~99 ages; Test scope of height: 90~200cm

External expansion project

Ultrasonic Height Measurer(selective purchasing)

Multi function body fat analyzer composite health analyser weight measurement

1.Product Introduction:

Body composition analyzer adopt multi-frequency bioelectrical impedance test method and using eight-point contact electrode to test the

different parts’ bio impedance of human body.According to the biological characteristics of human body, due to different composition of

human body has different bio impedance, it can detect the content of a variety of human body composition,muscle fat analysis, obesity

analysis, health assessment, weight management and many other indicators,and accurately analyze various composition of the human body

and compare the test results with standard reference values then analyze the health situation of human body.

2.Product Advantages:

Technical advantages:Adopt the neural network analysis method,automatic and intelligent analysis the test data, not rely on empirical value

estimation, the test results are accurate and reliable,can test various special body types accurately;

Multi-frequency segmentation:multi-frequency,subsection (left upper limb, right upper limb, trunk, right lower limb and left lower limb)

bioelectrical impedance test technology.using multi-frequency technology, especially frequencies above 250 khz , can accurately test the

moisture of inside and outside the cell and the body's total moisture;

Test method:Using the eight point contact electrode method can test the whole body composition;

High-definition touch: complete touch screen design, intuitive interface, easy to operate;

Accurate and stable: the instrument has good stability, high test accuracy and good repeatability;

Test Items: body composition analysis, muscle fat analysis, obesity analysis, weight

management, health assessment, etc.;

Convenient and quick:complete all tests within 1 minute, and the test results are convenient to query
